| self | dotsReadableHIDButtons () |
| | Simple subclass for a button box that maps button presses to keyboard presses. More...
|
| |
| self | dotsReadableHIDKeyboard (devicePreference) |
| | Get rid of annoying rollover event. More...
|
| |
|
self | dotsReadableHID () |
| | Constructor takes no arguments.
|
| |
| | flushData (self, varargin) |
| | Clear data from this object and the mexHID() internal queue. More...
|
| |
| components | setComponentCalibration (self, namesOrIDs, rawRange, deadRange, calibratedRange, granularity) |
| | Adjust scaling of raw values from HID components. More...
|
| |
| event | defineEvent (self, name, varargin) |
| | Define a calibrated event for given component. More...
|
| |
|
self | dotsReadable () |
| |
Constructor takes no arguments.
|
| |
|
| initialize (self) |
| |
Locate, acquire, configure, etc. device and component resources.
|
| |
| | calibrate (self, varargin) |
| |
Calibrate the device
More...
|
| |
| | record (self, onFlag, filename) |
| |
Open/close data file associated with the device Arguments: onFlag ...
More...
|
| |
| | reset (self, varargin) |
| | reset device More...
|
| |
|
| close (self) |
| |
Release any resources acquired by initialize().
|
| |
|
| delete (self) |
| |
Automatically close when Matlab is done with this object.
|
| |
| | read (self) |
| |
Add incoming data to history and detect events of interest.
More...
|
| |
| | flushData (self, waitForNoEvents) |
| |
Delete historical data and reset the current state.
More...
|
| |
| | logData (self) |
| |
Record current and historical data in topsDataLog.
More...
|
| |
| stateAtTime | getState (self, time) |
| |
Get the state of device components as of the given time.
More...
|
| |
| value data | getValue (self, ID) |
| |
Get the latest value for the given component.
More...
|
| |
| event | defineEvent (self, name, varargin) |
| |
Define the event of interest for one of the input components.
More...
|
| |
| | defineEventsFromComponents (self, names, varargin) |
| | defineEventsFromComponents More...
|
| |
| | defineEventsFromStruct (self, eventStruct, setName, keepExisting, inactivate) |
| | defineEventsFromStruct More...
|
| |
|
| showActiveEvents (self) |
| | Mostly for debugging.
|
| |
|
| activateEventSet (self, name) |
| | Swap in a set of events.
|
| |
| | activateEvents (self) |
| | Activate all events. More...
|
| |
| | deactivateEvents (self) |
| | Deactivate all events. More...
|
| |
|
activeFlags | getActiveFlags (self) |
| | Get all active flags.
|
| |
|
| setActiveFlags (self, activeFlags) |
| | Set all active flags from array.
|
| |
| | setEventsActiveFlag (self, activateList, deactivateList) |
| | Set/unset activeFlag. More...
|
| |
| name data | getNextEvent (self, isPeek, acceptedEvents) |
| |
Get the next event that was detected in read().
More...
|
| |
| lastName lastID names IDs | getHappeningEvent (self, time) |
| |
Get events that are happening at the current time.
More...
|
| |
|
name waitTime data | waitForEvents (self, eventNames, maxWait) |
| | Wait for event(s)
|
| |
| nEvents | getNumberOfEvents (self) |
| |
Get the number of events in eventQueue.
More...
|
| |
| IDs | getComponentIDs (self) |
| |
Get an array of unique integer component IDs.
More...
|
| |
|
ID | getComponentID (self, nameOrID) |
| |
Get ID of component by name or ID
|
| |
|
name | getComponentName (self, nameOrID) |
| |
Get name of component by name or ID
|
| |
|
indices | getComponentIndicesByID (self, IDs) |
| |
Get array of indices for the given component IDs
|
| |
|
indices | getComponentIndicesByName (self, names) |
| |
Get array of indices for the given component names
|
| |
|
time | getDeviceTime (self) |
| |
Get the current time from clockFunction.
|
| |
|
| setDeviceTime (self, val) |
| |
Set the device time
|
| |
| | startTrial (self, varargin) |
| |
startTrial()
More...
|
| |
| | finishTrial (self, varargin) |
| |
finishTrial()
More...
|
| |
| | plotData (self) |
| |
Open a figure with continuously read device data.
More...
|
| |
|
| startTrialDevice (self, varargin) |
| | Overloaded methods.
|
| |
|
|
static didHappen waitTime | waitForButton (buttonNumber, maxWait) |
| | For testing.
|
| |
| static kbs | openManyKeyboards () |
| | Open all of the available HID keyboards. More...
|
| |
| static | closeManyKeyboards (kbs) |
| | Close several HID keyboards. More...
|
| |
| static isPressed data kb | isKeyPressed (kbs, keyName) |
| | Is the given key pressed, on one or many keyboards? More...
|
| |
| static didHappen waitTime data kb name | waitForKeyPress (kbs, keyName, maxWait, flush, waitForRelease) |
| | Wait for given key to be pressed, on one or many keyboards. More...
|
| |
|
static | mexHIDQueueCallback (self, newData) |
| | Pass data from the mexHID() internal queue to Matlab. For newData, Rows are inputs Columns are.
|
| |
|
static time | currentHIDTime () |
| | Get the current time from the system USB/HID implementation.
|
| |
| static isHappening data readable | isEventHappening (readables, eventName) |
| |
Is the named event happening now?
More...
|
| |
| static didHappen waitTime data readable name | waitForEvent (readables, eventName, maxWait) |
| |
Wait for the named event to happen.
More...
|
| |
| static data | loadDataFile (filename, varargin) |
| | Load data from file. More...
|
| |
|
| Property | keyMatching |
| | Example usage: kb = dotsReadableHIDKeyboard(); [isPressed, waitTime, data, kbout] = dotsReadableHIDKeyboard.waitForKeyPress(kb, 'KeyboardF', 5, true) More...
|
| |
| Property | VendorIDs |
| | matching preferences read from machine defaults ... More...
|
| |
|
Property | deviceInfo |
| | struct of info about the HID device
|
| |
| Property | deviceMatching |
| | struct of HID parameters for identifying suitable HID devices. More...
|
| |
| Property | devicePreference |
| | struct of HID parameters for choosing among suitable devices. More...
|
| |
| Property | queueDepth = 1024 |
| | size of the mexHID() internal data queue More...
|
| |
|
Property | queueIsOpen = false |
| | whether or not the internal data queue opened successfully
|
| |
|
Property | isExclusive = false |
| | whether or not to get exclusive access to device data
|
| |
|
Property | allowMultipleConnections = false |
| | whether or not to allow multiple objects to access the same device
|
| |
|
Property | isAvailable = false |
| |
whether or not the object is ready to read() from
|
| |
|
Property | components |
| |
struct array with details about each component
|
| |
|
Property | state |
| |
matrix of ID, latest value, and latest time indexed by ID
|
| |
|
Property | history |
| |
matrix of component ID, value, and time from previous read()
|
| |
|
Property | isAutoRead = true |
| |
whether or not to to invoke read() during getValue(), etc.
|
| |
|
Property | eventDefinitions |
| |
struct array defining events of interest, indexed by ID
|
| |
|
Property | initialEventQueueSize = 100 |
| |
initial size of queue for events of interest
|
| |
|
Property | clockFunction |
| |
any function that returns the current time as a number
|
| |
|
Property | filename |
| |
name of the data file for devices that store their own data
|
| |
|
Property | filepath |
| |
where the file is
|
| |
|
Property | recordDuringCalibration = true |
| |
controls whether or not to stop recording during calibration
|
| |
|
Property | useGUI = false |
| | Flag to use GUI for feedback, etc.
|
| |
|
Property | useExistingCalibration = false |
| | Flag to skip calibration routine.
|
| |
|
Property | calibrationUI |
| | Possibly use a keyboard or other UI to help with calibration.
|
| |
|
Property | deactivateEventsAtStartTrial =false |
| | Flag to deactivate all events at the beginning of each trial.
|
| |
| Property | deviceID |
| | device identifier from mexHID('openMatchingDevice') More...
|
| |
| Property | queueCallback = @dotsReadableHID.mexHIDQueueCallback |
| | Callback which mexHID() uses to pass HID data to Matlab. More...
|
| |
|
Property | queueCallbackData |
| | matrix of recent data passed in from mexHID()
|
| |
|
Property | eventQueue |
| |
array of queued events (row indices into history)
|
| |
|
Property | queueNext |
| |
queue index of the next event to be dequeued
|
| |
|
Property | queueLast =0 |
| |
queue index of the last event enqueued
|
| |
|
Property | isRecording =false |
| |
keep track of whether device is currenly writing to a data file
|
| |
|
Property | didCalibrate = true |
| | Keep track of whether calibration occurs.
|
| |
|
Property | defaultEventPrefix = 'event' |
| | Default prefix for event names: <prefix>_<componentName>
|
| |
|
Property | eventSets |
| | Strutures with different named event definitions, in case we want to quickly swap between them.
|
| |
|
components | openComponents (self) |
| | Locate and enqueue all the keys of the keyboard.
|
| |
|
| closeComponents (self) |
| | Unenqueue all the keys of the keyboard.
|
| |
|
isOpen | openDevice (self) |
| | Find the best available HID device with mexHID().
|
| |
|
| closeDevice (self) |
| | Release mexHID() resources for this device.
|
| |
| isOpen | openHIDQueue (self, cookies) |
| | Open a queue to record value changes for device elements. More...
|
| |
| newData | readNewData (self) |
| | Pass any data from the mexHID() internal queue to this object(). More...
|
| |
| isOpen | openDevice (self) |
| |
Locate and acquire input device resources (for subclasses).
More...
|
| |
| | closeDevice (self) |
| |
Release input device resources (for subclasses).
More...
|
| |
|
| resetDevice (self, varargin) |
| | Reset the device.
|
| |
| status | calibrateDevice (self, varargin) |
| |
Calibrate the device (for subclasses).
More...
|
| |
|
isRecording | startRecording (self) |
| |
Turn on data recording from the device (for subclasses).
|
| |
|
isRecording | stopRecording (self) |
| |
Turn off data recording from the device (for subclasses).
|
| |
| components | openComponents (self) |
| |
Locate and acquire device components (for subclasses).
More...
|
| |
| | closeComponents (self) |
| |
Release device components (for subclasses).
More...
|
| |
| newData | readNewData (self) |
| |
Read and format incoming data (for subclasses).
More...
|
| |
| isEvent | detectEvents (self, data) |
| |
Use new data to look up events of interest (used internally).
More...
|
| |
| newSize | resizeEventQueue (self, minSize, doClear) |
| |
Resize and optionally clear the event queue (used internally).
More...
|
| |
| nEvents | enqueueEvents (self, eventValues) |
| |
Add events of interest to the event queue (used internally).
More...
|
| |
| eventValue nEvents | dequeueEvent (self, isPeek) |
| |
Remove the next queued event of interest (used internally).
More...
|
| |
Methods inherited from dotsReadableHIDKeyboard
